Acumulator™ Ready Mix Concrete Batch Plant

Acumulator Ready Mix Concrete Batch Plant
The Decumulator ready mix batch plant manufactured by JEL Concrete Plants.

Our Acumulator concrete plant is an accumulative weighing system that can be set up for low or high production. This traditional concrete plant design uses a multi compartment overhead aggregate storage bin.

GET A FREE QUOTE ...or calculate the cost of your concrete batch plant with an ROI estimate.

This is a great design for a start-up operation, as it allows you to start with a small, low cost plant and then add upgrades to accommodate higher production in the future.

As with all JEL concrete plants, our innovative design and manufacturing strategies enable us to build affordably priced plants with no compromise to quality.

Typical Specifications

  • 550 bbl. silo. Other sizes available upon request
  • 14 cu. yd. cement batcher
  • 2, 3 or 4 compartment, 120-ton aggregate bin. Other sizes available upon request.
  • 30″ transfer conveyor
  • 3″ metered water
  • Batchtron automatic control system
  • 120+ cu. yds. per hour production rating
  • 5 days setup supervision / onsite training

Popular Options

  • Load point dust collection – 6000+ CFM, 5:1 air/cloth ratio or less
  • Weighed Water – Water holding tank gravity feeds weigh hopper. Includes level sensors, load cells and water shut-off valve.
  • 36″ transfer conveyor
  • Radial stacker or automatic feed system



Contact JEL Concrete Plants to discuss your options and get a quote on your custom system.

Custom Ready Mix & Precast Concrete Batch Plant Design & Installation

We produce high-quality dry & wet ready mix, precast and central mix concrete plants at pricing routinely beating our competitors. Proudly made in America by skilled craftsmen near Milwaukee WI, an area well known for high quality construction and mining equipment manufacturers, JEL Concrete Plants’ quality is second to none. Call 262-223-3205 to discuss the concrete plant configuration & calibration perfect for your production specifications.
